At Rajat Steel & Engg. Co., our Hastelloy piping is known for its superior resistance to localized corrosion, cracking, and stress corrosion cracking. Manufactured with precision and adhering to international quality standards, these pipes are ideal for challenging environments in chemical processing, power plants, and aerospace industries. Hastelloy’s exceptional durability ensures reliable performance even under extreme conditions. We offer a wide range of sizes and specifications to meet your critical piping needs with timely delivery and trusted quality.
Among the wide variety of nickel-base pipes available in the market. Hastelloy C276 Hexagonal Pipe is one of the many nickel-based alloy pipes. Along with nickel as the primary element DIN 2.4819 Hexagonal Pipe also has molybdenum and chromium added to it. Due to chromium being added to C276 Hastelloy Hollow Pipe they can resist oxidizing environment. Hastelloy c276 seamless pipe can resist corrosion in an extreme environment. An element of tungsten is also added to ASTM B622 UNS N10276 Seamless Pipe. If you need an improved version of alloy C C276 Hastelloy ERW Pipe is the one. Usually, pipes need to be solution treated however, Alloy C276 Seamless Pipe doesn’t need to be solution treated. Astm B626 Nickel Alloy C276 Welded Pipe and alloy C have one more difference i.e Alloy C276 Pipe have better fabricability.
On the other hand, Alloy C276 Boiler tubes are available in the specification of ATSM 622/ 619/ 775/ 516/ 626. Hastelloy C276 Seamless Tube performs well even in salty corrosive seawater. Hastelloy Tube Manufacturers recommend Astm B626 C276 Hastelloy Welded Tube to resist chloride-containing compounds. Alloy C276 Heat Exchanger Tube can be processed by automatic shape, annealing with nitrogen protection, ultrasonic, and cold draw. Hastelloy C276 Tube is used in decoration construction and the food industry. We at Victor Steel are Hastelloy tube suppliers across India and provide our clients the best possible solution as per their requirements.
| Category | Specifications / Details |
|---|---|
| ASTM Specification | ASTM B619, ASTM B622, ASTM B516, ASTM B775, ASTM B626 |
| International Specification | DIN 17751, ISO 6207, VdTüV 400/12.98 |
| Standard | AMS, JIS, NF, DIN, ASTM, AISI, SAE, GB, DS, EN, ASME, TOCT, DTD |
| Size of Welded Pipe | 5.0 to 1219.02 millimeter |
| Size of Seamless Pipe | Wall thickness: 0.05 - 20 millimeter, 4 - 219 millimeter |
| Seamless Tube Size | 3.35 millimeter to 101.6 millimeter OD |
| Size of EFW Pipe | 5.0 to 1219.02 millimeter |
| Welded Tube Size | 6.35 millimeter to 152 millimeter OD |
| Tubing Wall Thickness | 0.020" – 0.220" (custom wall thicknesses available) |
| BWG & SWG | 18 Swg., 14 Swg., 20 Swg., 12 Swg., 16 Swg., 10 Swg. |
| Length | Standard & Cut length, Single Random, Double Random Pipe |
| Pipe Schedule | SCH80, XXS, SCH10S, SCH5, XS, SCH120, SCH160, SCH140, SCH30, STD, SCH40S, SCH40, SCH10, SCH60, SCH20 |
| End | Plain End, Beveled End, Threaded Pipe, Screwed Ends |
| Finish | AP (Annealed & Pickled), BA (Bright & Annealed), NO.1, 2B, Polished, MF, HL, NO.4, Mirror Finish, 8K |
| Pipe Application | Dairy Pipe, Oil Pipe/tube, Gas Pipe/tube, Fluid Pipe/tube, Boiler Tube, Heat Exchanger Tube |
| Form | Round, Hollow, Hydraulic, Square, Rectangular, Coiled, Straight Pipes/tubes, “U” Shape, Pan Cake Coils, Boiler, LSAW |
